Effective Groundwater Control with Slurry Wall

Slurry wall is a ground improvement technique that uses non-structural underground barriers to build cut-off walls to prevent the flow of water.

Slurry wall Menard picto


For depths of less than 20 meters, an excavator is generally used to dig a low permeability slurry wall in a highly efficient process. The excavated materials are mixed with clay and bentonite and then used as fill as appropriate. The technique therefore generates very little spoil. It delivers very low values of permeability, in the order of 10-7 to 10-9 ms.

Why build a Slurry Wall?

It is often used as a remediation technique to limit migration of contaminants from one site to the other via a natural water flow gradient.


The trench is dug using a continuous mechanical excavator under bentonite slurry to stabilize the wall during excavation. For depths greater than 20 meters, a grab can be used.

Contact us today to ensure the safe and reliable operation of your industrial plant and equipment. Our foundation solutions are tailored to your unique needs and soil conditions, providing cost-effective and durable results.

Slurry Walls FAQs

What is the mechanical strength of a slurry wall?2023-03-09T13:28:17+01:00

The slurry wall has virtually no mechanical strength and cannot therefore be used as a retaining wall. It can be subject to erosion and cannot withstand large hydraulic gradients.
